The Cars
RR14
Competitions: Formula SAE Michigan 2014, Formula North 2014
Specifications
Weight: 435 lbs
Wheelbase: 60.5 in
Track Width (F/R): 50 in / 48 in
Chassis: 1020 Steel Tubular Space Frame
Suspension: Double A-arm, Pushrod Actuated
Tires: Hoosier 20.5x7-13 R25B
Engine: Yamaha WR250R Single Cylinder
Displacement: 250cc
Compression Ratio: 12.5:1
Max Engine Speed: 10,000 RPM
Fuel: 94 Octane
ECU: MOTEC M48
Ignition: SPDi Spark
RR13
Competitions: Formula SAE Michigan 2013, Formula North 2013
Specifications
Weight: 433 lbs
Wheelbase: 60.5 in
Track Width (F/R): 48 in / 46 in
Chassis: 1020 Steel Tubular Space Frame
Suspension: Double A-arm, Pushrod Actuated
Tires: Hoosier 20.5x7-13 R25B
Engine: Yamaha WR250R Single Cylinder
Displacement: 250cc
Compression Ratio: 12.5:1
Max Engine Speed: 10,000 RPM
Fuel: 94 Octane
ECU: Stock
RR13H
Competitions: Formula Hybrid 2013, Formula North 2013
Specifications
Weight: 740 lbs
Wheelbase: 60.5 in
Track Width (F/R): 49.5 in / 47.5 in
Chassis: 1020 Steel Tubular Space Frame
Suspension: Double A-arm, Pushrod Actuated
Tires: Hoosier 20.5x7-13 R25B
Engine: Yamaha WR250R Single Cylinder
Displacement: 250cc
Compression Ratio: 12.5:1
Max Engine Speed: 10,000 RPM
Fuel: 94 Octane
ECU: Stock
Electric Motor: 2 x Agni 95R
Batteries: K2 Energy K2B3V41P
RR12
Competitions: Formula North 2012
Specifications
Weight: 433 lbs
Wheelbase: 60.5 in
Track Width (F/R): 48 in / 46 in
Chassis: 1020 Steel Tubular Space Frame
Suspension: Double A-arm, Pushrod Actuated
Tires: Hoosier 20.5x6-13 R25A
Engine: Yamaha WR250R Single Cylinder
Displacement: 250cc
Compression Ratio: 12.5:1
Max Engine Speed: 10,000 RPM
Fuel: 94 Octane
ECU: Stock
RR10
Competitions: Formula SAE Michigan 2010
Specifications
Weight: 399 lbs
Wheelbase: 60.5 in
Track Width (F/R): 48 in / 46 in
Chassis: 1020 Steel Tubular Space Frame
Suspension: Double A-arm, Pushrod Actuated
Tires: Hoosier 20.5x6-13 R25A
Engine: KTM 525 Single Cylinder
Displacement: 510cc
Compression Ratio: 11.0:1
Max Engine Speed: 10,000 RPM
Fuel: 94 Octane
ECU: MOTEC M48
Ignition: VIMX
RR09
Competitions: Formula SAE Michigan 2009
Specifications
Weight: 399 lbs
Wheelbase: 60.5 in
Track Width (F/R): 47.5 in / 45.5 in
Chassis: 1020 Steel Tubular Space Frame
Suspension: Double A-arm, Pushrod Actuated
Tires: Hoosier 20.5x6-13 R25A
Engine: KTM 525 Single Cylinder
Displacement: 510cc
Compression Ratio: 11.0:1
Max Engine Speed: 10,000 RPM
Fuel: 94 Octane
ECU: MOTEC M48
Ignition: VIMX
RR08
Competitions: Formula SAE Michigan 2008
Specifications
Weight: 400 lbs
Wheelbase: 60 in
Track Width (F/R): 46 in / 44 in
Chassis: 1020 Steel Tubular Space Frame
Suspension: Double A-arm, Pushrod Actuated
Tires: Hoosier 20.5x6-13 R25A
Engine: KTM 525 Single Cylinder
Displacement: 510cc
Compression Ratio: 11.0:1
Max Engine Speed: 10,000 RPM
Fuel: 94 Octane
ECU: MOTEC M48
Ignition: VIMX
RR07
Competitions: Formula SAE Michigan 2007
Specifications
Weight: 449 lbs
Wheelbase: 60 in
Track Width (F/R): 46 in / 44 in
Chassis: 1020 Steel Tubular Space Frame
Suspension: Double A-arm, Pushrod Actuated
Tires: Hoosier 20.5x6-13 R25A
Engine: KTM 525 Single Cylinder
Displacement: 510cc
Compression Ratio: 11.0:1
Max Engine Speed: 10,000 RPM
Fuel: 94 Octane
ECU: MOTEC M48
Ignition: VIMX
C06
Competitions: Formula SAE Michigan 2006
Specifications
Weight: 410 lbs
Wheelbase: 63 in
Track Width (F/R): 48.5 in / 46 in
Chassis: 1020 Steel Tubular Space Frame
Suspension: Double A-arm, Pushrod Actuated
Tires: Goodyear 20x6.5-13 R065
Engine: KTM 450sx Single Cylinder
Displacement: 576cc
Compression Ratio: 12.5:1
Max Engine Speed: 10,000 RPM
Fuel: 94 Octane
ECU: MOTEC M48
Ignition: VIMX
C05
Competitions: Formula SAE Michigan 2005
Specifications
Weight: 430 lbs
Wheelbase: 65 in
Track Width (F/R): 48.7 in / 46 in
Chassis: 1020 Steel Tubular Space Frame
Suspension: Double A-arm, Pushrod Actuated
Tires: Goodyear 20x6.5-13 R065
Engine: KTM 450sx Single Cylinder
Displacement: 576cc
Compression Ratio: 12.5:1
Max Engine Speed: 10,000 RPM
Fuel: 94 Octane
ECU: MOTEC M48
C04
Competitions: Formula SAE Michigan 2004
Specifications
Weight: 440 lbs
Wheelbase: 65 in
Track Width (F/R): 52 in / 50 in
Chassis: 1020 Steel Tubular Space Frame
Suspension: Double A-arm, Pushrod Actuated
Tires: Goodyear 20x6.5-13 R065
Engine: Honda CBR600-F3 4-Cylinder
Displacement: 599cc
Compression Ratio: 12.0:1
Max Engine Speed: 10,000 RPM
Fuel: 100 Octane
ECU: TEC II
C03
Competitions: Formula SAE Michigan 2003
Specifications
Weight: 490 lbs
Wheelbase: 65.7 in
Track Width (F/R): 52 in / 50 in
Chassis: 1020 Steel Tubular Space Frame
Suspension: Double A-arm, Pushrod Actuated
Tires: Goodyear 20x6.5-13 R065
Engine: Honda CBR600-F3 4-Cylinder
Displacement: 599cc
Compression Ratio: 12.0:1
Max Engine Speed: 10,000 RPM
Fuel: 100 Octane
ECU: TEC II
RR1999
Competitions: Formula SAE Michigan 1999
C02
Competitions: Formula SAE Michigan 2002
RR15
Competitions: Formula North 2015, Formula SAE Lincoln 2015
Specifications
Weight: 440 lbs
Wheelbase: 61 in
Track Width (F/R): 50 in / 48 in
Chassis: 1020 Steel Tube / Composite Hybrid Frame
Suspension: Double A-arm, Pushrod Actuated
Tires: Hoosier 20.5x7-13 R25B
Engine: Yamaha WR250R Single Cylinder
Displacement: 250cc
Compression Ratio: 12.5:1
Max Engine Speed: 10,000 RPM
Fuel: 94 Octane
ECU: MOTEC M48
Ignition: SPDi Spark
RR15E
Competitions: Formula North 2015, Formula SAE Electric 2015
Specifications
Weight: 547 lbs
Wheelbase: 61 in
Track Width (F/R): 50 in / 48 in
Chassis: 1020 Steel Tube / Composite Hybrid Frame
Suspension: Double A-arm, Pushrod Actuated
Tires: Hoosier 20.5x7-13 R25B
Motor: Enstroj EMRAX 228 HV LC
Controller: Unitek BAMOCAR D3
Batteries: 84 x LiFePO4
Electronics: Custom
Max Voltage: 300V
Max Current: 250A
Energy Capacity: 5.5kWh
